Bendigo Timber - LVL Structural Beams

Laminated Veneer Lumber (LVL) is a construction timber uniformly engineered with a high strength to weight ratio and available in long lengths. The E14 graded LVL provides the equivalent performance of F17 hardwood, with H2S treatment for termites in above-ground weather protected applications.

LVL SupaRed E14

E14 Structural
F17 Equivalent
H2S Termi Treat

Span Tables

LVL SupaRed E14/F17 H2 BeamsAvailability
LVL Beam SupaRed (E14/F17 H2S) 90 x 45mm per LM	SR904510	3.6m 4.8m 5.4m 6.0m 7.2m
LVL Beam SupaRed (E14/F17 H2S) 140 x 45mm per LM	SR1404510	3.6m 4.8m 5.4m 6.0m 10.8m
LVL Beam SupaRed (E14/F17 H2S) 190 x 45mm per LM	SR1904510	3.6m 4.8m 5.4m 6.0m 7.2m 12m
LVL Beam SupaRed (E14/F17 H2S) 240 x 45mm per LM	SR2404510	3.6m 4.8m 5.4m 6.0m 7.2m 12m
LVL Beam SupaRed (E14/F17 H2S) 290 x 45mm per LM	SR2904510	3.6m 4.8m 5.4m 6.0m 7.2m 12m
LVL Beam SupaRed (E14/F17 H2S) 360 x 45mm per LM	SR3604510	Up to 12.0m in 0.6m increments
LVL Beam SupaRed (E14/F17 H2S) 400 x 45mm per LM	SR4004510	6m 12m

LVL E14 / F17

E14 Structural
F17 Equivalent
H2S Termite Protection

Design

LVL F17 H2 Beams - 45mmAvailability
LVL Beam E14/F17 H2S Treated 90 x 45mm per LM	LV904510	3.6m 4.8m 5.4m 6.0m 7.2m
LVL Beam E14/F17 H2S Treated 120 x 45mm per LM	LV1204510	Order
LVL Beam E14/F17 H2S Treated 140 x 45mm per LM	LV1404510	3.6m 4.8m 5.4m 6.0m 7.2m
LVL Beam E13 H2S Treated 170 x 45mm per LM	LV1704510	Order
LVL Beam E14/F17 H2S Treated 190 x 45mm per LM	LV1904510	3.6m 4.8m 5.4m 6.0m 7.2m
LVL Beam E14/F17 H2S Treated 240 x 45mm per LM	LV2404510	3.6m 4.8m 5.4m 6.0m 7.2m
LVL Beam E14/F17 H2S Treated 290 x 45mm per LM	LV2904510	3.6m 4.8m 5.4m 6.0m 7.2m

LVL F17 H2 Beams - 35mmAvailability
LVL Beam E14/F17 H2S Treated 90 x 35mm per LM	LV903510	Order
LVL Beam E14/F17 H2S Treated 120 x 35mm per LM	LV1203510	Order
LVL Beam E14/F17 H2S Treated 140 x 35mm per LM	LV1403510	Order
LVL Beam E14/F17 H2S Treated 190 x 35mm per LM	LV1903510	Order
LVL Beam E14/F17 H2S Treated 240 x 35mm per LM	LV2403510	Order

I-Joist

Strong & Light
Untreated EWP
Up to 13.2m
H2S Optional

Engineered I-Joist 200-240mmAvailability
Engineered I-Joist 200 x 45mm per LM	IJ20045	Order
Engineered I-Joist 240 x 45mm per LM	IJ24045	Order
Engineered I-Joist 240 x 52mm per LM	IJ24052	Order
Engineered I-Joist 240 x 58mm per LM	IJ24058	Order
Engineered I-Joist 240 x 90mm per LM	IJ24090	Order

Engineered I-Joist 300mmAvailability
Engineered I-Joist 300 x 45mm per LM	IJ30045	Order
Engineered I-Joist 300 x 52mm per LM	IJ30052	Order
Engineered I-Joist 300 x 58mm per LM	IJ30058	Order
Engineered I-Joist 300 x 90mm per LM	IJ30090	Order

Engineered I-Joist 360-400mmAvailability
Engineered I-Joist 360 x 45mm per LM	IJ36045	Order
Engineered I-Joist 360 x 58mm per LM	IJ36058	Order
Engineered I-Joist 360 x 90mm per LM	IJ36090	Order

Formwork LVL

Water Resistant
Arrised Edges

Brochure

DindasEDGE Formwork LVLAvailability
DindasEDGE Formwork LVL E12 100 x 36mm per LM	LE10036	Order
DindasEDGE Formwork LVL E12 150 x 36mm per LM	LE15036	Order
DindasEDGE Formwork LVL E12 170 x 36mm per LM	LE17036	Order
DindasEDGE Formwork LVL E12 200 x 36mm per LM	LE20036	Order

Framing LVL

Stable & Straight
M10,M12 Alternative

Brochure

DindasFRAME LVLAvailability
DindasFRAME LVL12 H2S 90 x 35mm per LM	LF9035	Order
DindasFRAME LVL12 H2S 90 x 45mm per LM	LF9045	Order

LVL E13 H2 BeamsAvailability
LVL Beam E13 H2S Treated 90 x 63mm per LM	LV906310	3.6m 4.8m 5.4m 6.0m 7.2m
LVL Beam E13 H2S Treated 150 x 63mm per LM	LV1506310	Order
LVL Beam E13 H2S Treated 200 x 63mm per LM	LV2006310	Order
LVL Beam E13 H2S Treated 240 x 63mm per LM	LV2406310	Order
LVL Beam E13 H2S Treated 300 x 63mm per LM	LV3006310	Order
LVL Beam E13 H2S Treated 360 x 63mm per LM	LV3606310	Order
LVL Beam E13 H2S Treated 400 x 63mm per LM	LV4006310	Order
LVL Beam E13 H2S Treated 400 x 45mm per LM	LV4004510	Order
LVL Beam E13 H2S Treated 300 x 75mm per LM	LV3007510	Order
LVL Beam E13 H2S Treated 400 x 75mm per LM	LV4007510	Order
